International Shipping: 15 Days
| Brand | Engenius |
| Model Number | EWS 1025 |
| Type | Dome |
| Color | White |
| Standards | IEEE 802.11b/g/n on 2.4 GHz IEEE 802.11a/n/ac on 5 GHz IEEE 802.3at/af IEEE 802.11r IEEE 802.11k IEEE 802.11i IEEE 802.11x |
| Antenna | 5dBi 5 GHz & 5dBi 2.4 GHz Internal High-Gain Antennas |
| Physical Interface | 1 x 100/1000 Gigabit Ethernet Port - Supports 802.3at/af PoE Input 1 x Reset Button 1 x Power Connector 1 x Micro SD/SDXC Slot 24 Pcs IR LEDs 1x Embedded Microphone |
| LED Indicators | 1 x Power 1 x 2.4 GHz 1 x 5 GHz 1 x Ethernet 1 x Mesh |
| Power Source | 24V Proprietary Compliant Source 12VDC/1.5A Active Ethernet (PoE) |
| Memory Capacity | Micro SD/SDXC β (up to 64G) |
| Image Sensor | Sony 1 /2.9β 2-Megapixel Progressive Scan CMOS |
| Lens | Fixed Board Lens Fixed-Focus f=2.8 mm / F2.0 |
| F.O.V. | 120Β° (diagonal) |
| IR Illuminator | 24 Pcs LEDs Up to 65 Feet |
| Day/Night | Removable IR-Cut Filter |
| Minimum Illumination | Color (IR-Off) 0.01 Lux / F2.0 B/W (IR-On) 0 Lux / F2.0 |
| Shutter Time | 1/2 sec. to 1/10000 sec. |
| Compression | H.264/MJPEG |
| Stream | 2x Video Streams |
| Frame Rates | Up to 30 FPS at 1920 x 1080P |
| Audio Streaming | 1-Way |
| Interface | Built-In Microphone |
| Wireless & Radio Specifications | Dual-Concurrent Radio |
| Operation Modes | Mesh Access Point/Access Point |
| Standalone | Access Point; Client Bridge; WDS Access Point; WDS Bridge; WDS Station |
| Multiple BSSID | Supports up to 16 SSIDs 8 SSIDs per Radio |
| VLAN Tagging | Supports 802.1q SSID-to-VLAN Tagging VLAN Pass-Through |
| Spanning Tree | Supports 802.1d Spanning Tree Protocol |
| QoS | Compliant with IEEE 802.11e Standard WMM |
| Transmit Power | Up to 21dBi on 2.4 GHz Up to 19dBi on 5 GHz |
| Security | WEP Encryption (64/128/152 bit) WPA/WPA2 Enterprise (PSK using TKIP or AES) Hide SSID in Beacons MAC Address Filtering Up to 50 MACs per SSID SSH Support Client Isolation |
| Package Contents | EWS1025CAM 12V/1.5A Power Adapter Mounting Bracket Mounting Screw Set T-Rail Mounting Kit RJ45 Ethernet Cable Quick Installation Guide |
